Did you know that you can make your Harley Davidson turn signal not only function as a regular signal, but also as a runbrake and runturn? It's a simple modification that can greatly enhance the visibility of your bike on the road, increasing safety for both you and other drivers.

But how exactly can you achieve this? Well, in this discussion, we will guide you through the steps and provide you with the necessary tools and materials to make your Harley Davidson turn signal a versatile and efficient lighting system.

So, if you're looking to take your bike's visibility to the next level, keep reading to discover how to make your Harley Davidson turn signal runbrake runturn.

Key Takeaways

Gather the necessary tools and materials, including a screwdriver, wire stripper, and Run/Brake/Turn Module from a dealership, for the installation process.
Disconnect the negative battery cable before starting the installation for safety purposes.
Connect the wiring harness of the Turn Signal Runbrake Runturn kit to the rear turn signal wires and the Accessory Adapter to the new wiring for brake lights.
Test the Runbrake Runturn function by activating the turn signals, brake lights, and running lights to ensure proper functionality.

Table of Contents

Installation Steps

Are you ready to dive into the technical and precise installation steps for making a Harley Davidson Turn Signal Runbrake Runturn? Well, get ready to liberate your ride with this plug and play upgrade that combines your rear turn signals and brake light into one stylish and functional unit. Follow these installation steps to enhance both the safety and aesthetic appeal of your Harley Davidson.

First, gather all the necessary tools and materials. You'll need a screwdriver, wire stripper, electrical tape, and the Turn Signal Runbrake Runturn kit. Begin by disconnecting the negative battery cable to ensure safety during the installation process.

Next, locate the rear turn signal wires on your Harley Davidson. Carefully remove the existing turn signals by unscrewing them from the mounting brackets. Now, connect the wiring harness of the Turn Signal Runbrake Runturn kit to the rear turn signal wires, making sure to match the colors correctly.

Once the wiring is connected, mount the Turn Signal Runbrake Runturn unit onto the rear fender using the provided screws. Ensure that it's securely attached to avoid any potential damage while riding.

Required Tools and Materials

To successfully install the Harley Davidson Turn Signal Runbrake Runturn, you'll need a specific set of tools and materials. Here are the required tools and materials you'll need:

Run/Brake/Turn Module from the dealership: The module is a crucial component of the installation process. It allows your rear turn signals to act as running lights, brake lights, and turn signals simultaneously, improving visibility and safety.
Soldering iron and solder: These tools are necessary for connecting wires and ensuring a secure and reliable electrical connection. Make sure to use a high-quality soldering iron and solder to achieve a strong bond.
Heat shrink tubing: Heat shrink tubing is used to protect and insulate the soldered connections. It provides an additional layer of protection against moisture, corrosion, and other environmental factors.
Wire cutters and strippers: These tools are essential for cutting and stripping the wires to the appropriate length. They ensure clean and precise wire connections, eliminating the risk of frayed or damaged wires.
Red lenses or red LEDs suitable for the modification: To comply with legal requirements, you'll need red lenses or red LEDs that are compatible with your Harley Davidson model. These will replace the existing turn signal lenses, allowing for the desired run/brake/turn functionality.

Adjusting the Runbrake Runturn Function

To adjust the Runbrake Runturn function, you'll need to follow these precise steps.

First, make sure you have the necessary tools and materials, including an Accessory Adapter and a Glide. Once you have everything ready, you can begin the adjustment process.

Here are the steps you need to take to adjust the Runbrake Runturn function:

Start by locating the rear lighting wiring harness on your Harley Davidson. This is usually found under the seat or behind the fender.
Disconnect the wiring harness from the brake lights.
Connect the Accessory Adapter to the wiring harness and secure it in place.
Connect the Accessory Adapter to the new wiring for the brake lights. Make sure the connections are secure and properly insulated.

Once you have completed these steps, you can test the Runbrake Runturn function to ensure it's working correctly. Activate the turn signals, brake lights, and running lights to see if they function as intended.

Troubleshooting Common Issues

If you encounter any issues with the Runbrake Runturn function on your Harley Davidson, here are some troubleshooting tips to help you resolve common problems:

Check the connections: Ensure that all the connections are secure and properly soldered. Loose or faulty connections can cause the Runbrake Runturn function to malfunction.
Verify the wiring: Double-check the wiring to make sure it's correctly connected to the appropriate terminals. Incorrect wiring can lead to improper functionality.
Inspect the module: Examine the Runbrake Runturn module for any signs of damage or corrosion. A faulty module can cause issues with the function. If necessary, replace the module with a new one.
Consider red lenses: If you have recently installed red lenses on your Harley Davidson, make sure they're compatible with the Runbrake Runturn function. Incompatible lenses can interfere with the proper functioning of the system.

Safety Precautions and Maintenance Tips

For optimal safety and proper functioning of your Harley Davidson's Runbrake Runturn system, it's crucial to follow these maintenance tips and safety precautions.

Regularly inspect your Road, Street Glide, or Electra Glide to ensure that all components of the Runbrake Runturn system are in good condition. Check for any loose wires, damaged connectors, or worn-out bulbs. Replace any faulty parts immediately to avoid any potential accidents on the road.

To maintain the functionality of the Runbrake Runturn system, keep it clean and free from dirt, debris, and moisture. Clean the lenses regularly using a mild soap solution and a soft cloth. Avoid using abrasive cleaners that may scratch the lenses. Additionally, make sure to check the electrical connections periodically to ensure they're secure and free from corrosion.

When installing or replacing bulbs, always use compatible bulbs that meet the specifications of your Harley Davidson model. Using incorrect bulbs can lead to poor visibility and compromised safety. It's also important to ensure that the Runbrake Runturn system is properly aligned and adjusted to provide optimum visibility to other road users.

Lastly, it's essential to ride responsibly and adhere to all traffic rules and safety precautions. Always signal your intentions using the Runbrake Runturn system to communicate effectively with other drivers. Regularly check the functionality of the system before hitting the road to ensure your safety and the safety of others.

Conclusion

In conclusion, by installing a run/brake/turn module or utilizing products like TailBones or the Auxiliary Brake Light / Running Light / Turn Signal Conversion Kit, you can transform your Harley Davidson turn signal into a runbrake runturn system.

This enhancement not only improves visibility and safety on the road, but also adds a new level of sophistication to your motorcycle, like a beacon of light guiding you through the darkness.

Ride with confidence and enjoy the enhanced functionality of your turn signals.
